Atlas® PX-16A Extra Long 16,000 Lbs. Capacity Commercial Grade Alignment Scissor Lift

Write a Review

SKU:

ATEATPK-PX16A-CF-KIT-FPD

UPC:

ATPK-PX16A-CF

Availability:

FACTORY SHIPPED

Shipping:

Calculated at Checkout

Description
Videos
Reviews (0)

Description

Heavy Duty Construction and super-balanced lift for wheel alignment
Can be surfaced mounted or flush mounted
Very precise platform leveling accuracy
Recessed Turntables
Mechanical safety lock with air operated engagement and release
Emergency manual pump for lowering
Air Line Kit Routing System Included
Overload valve included
Lowering speed control valve included
Extra Long Slip Plates allow for 4-wheel aligning of wheelbases from 184" to 96"
6 month motor/electric, 2 year structural, and 1 year hydraulic warranty
Mounting Hardware Included
Shipping Weight: 6,200 lbs.

Atlas® PX-16A Extra Long 16,000 Lbs. Capacity Commercial Grade Alignment Scissor Lift

The Atlas® PX-16A (16,000 lb. capacity) scissor alignment lift is the perfect choice for those service shops that need a space saving (narrow width) alignment lift to accommodate most all passenger cars up to heavy-duty long wheel base trucks and vans.

The Atlas® PX-16A allows the operator to perform 4-wheel alignments for vehicles with wheel base lengths from 96 inches to 184 inches, and up to 204 inches with the optional set of front extensions.

The Atlas® PX-16A includes a set of turntables and the runway jack rail is designed to accommodate optional rolling jacks. The lift is equipped with a semi enclosed air line kit routing system to accommodate the optional airline kit. This air line kit will provide air to the rolling jacks and prevent shop air hoses from cluttering the floor.

This is perfect alignment lift for those service departments that do alignments on a variety of vehicles that may include a Smart Car® all the way to an F-450 dual wheel truck.

Atlas® PX-16A 16,000 LB Alignment Scissor Lift Specifications

Lifting Capacity												16,000 LB
Lifting Height												71 1/2" (5' 11 1/2")
Clearance Under Runway												63 3/4" (5' 3 3/4")
Overall Width												94" (7' 10")
Overall Length with Approach Ramps												271" (22' 7") 294" (24' 6") with extensions
Overall Length without Approach Ramps												206 1/2" (17' 2 1/2") 229 1/2" (19' 1 1/2") with extensions
Optional Extension Length												22 3/4"
Approach Ramp Length												66" (5' 6")
Slip Plate Length												82 3/8" (6' 10 3/8")
4-Wheel Alignment Wheelbase												Max. without extensions: 184" (15' 4") Max. with extensions: 204" (17') Min. 96" (8')
2-Wheel Alignment Wheelbase												Max. without extensions: 188 1/2" (15' 8 1/2") Max. with extensions: 210" (17' 6")
Runway Width												23 3/4" (1' 11 3/4")
Lowered Height												13 1/4"
Locking Positions												18
Width Between Runways												44 7/8" (3' 8 7/8")
Width Between Runway Rails												41 3/8" (3' 5 3/8")
Motor/Electrical Requirement												2 HP 220 volt +/- 5% (209-231volts) single (1) phase. A 30 amp breaker is required.
Oil Requirement												3.5 Gallons AW32/AW46
Shipping Weight												6200 lbs.
