Launch Red 9,000 Lbs Capacity Clear Floor Asymmetric 2 Post Lift-

The TLT240SB-R 2 Post Car Lift by Launch Tech USA

Ever wished you could lift your ride as easily as you lift your coffee mug? Meet the TLT240SB-R Car Lift - the Hercules of your garage that can hoist a staggering 9,000 lbs. This towering titan stands 151" tall, offering a lift height of 73" that'll make your car feel like it's on cloud nine. And with a lifting speed of 50 seconds, it's faster than your mechanic's coffee break!

But hold onto your wrenches because this lift is more than just muscle. It's got asymmetric and symmetric widths of 140" and 134", adapting to your space like a chameleon. The clear floor design gives you more room to moonwalk under your vehicle, while the 4" minimum pad height means even your lowered street racer can get a lift. With arms that extend from 23-5/8" to 54", it's got a reach that'd make Mr. Fantastic jealous. Powered by 220V and tipping the scales at 1,600 lbs, this lift is ready to transform your garage into a professional-grade workshop. So, why crawl when you can stand tall? Grab the TLT240SB-R and take your auto work to new heights.

2 Post Car Lift TLT240SC-R Specification:

• Capacity: 9,000 lbs.
• Height Overall: 151″
• Width Overall w/ Power Unit (Asymmetric): 140″
• Width Overall w/ Power Unit (Symmetric): 134″
• Max Lift Height: 73″
• Width Between Columns: 108″
• Min. Pad Height: 4″
• Drive Thru Clearance (Asymmetric): 95″
• Drive Thru Clearance (Symmetric): 98″
• Lifting Speed: 50 seconds
• Clear Floor / Floor Plate: Clear Floor
• Short Arm Reach – min/max: 23-5/8″ - 43-1/2″
• Long Arm Reach – min/max: 34″ - 54″
• Narrow Bay Setting: Deduct 5.9″
• Max Load Per Arm: 2,250 lbs.
• Ship Weight: 1,600 lbs.
• Power: 220V, 20 AMP, 1 PH
• Pallet Dimensions: 110" 24" 48"

TLT240SC-R 2 Post Car Lift Special Features:

• 9,000 lbs Capacity
• Chain Drive
• Rubber Door Guards
• Hose Guards
• Dual Point Lock Release
• Heavy Duty Arm Restraint System
• Double Telescoping Screw Pads
• Adjustable Column Width
• Standard or Rotated Asymmetric Columns
• 3 Stage Front Arms
• Stackable Pad extensions
• Warranty: 5 Years Structure, 1 Year Parts - Under Normal Use

Features Adjustable Column Width Provides extra 6” of width adjustment for narrow service bays to custom fit your shop (TLT240SC Only). Rubber Door Guards Provides added security against door damage. Hose Guards Protects hydraulic hoses from damage. Dual Point Lock Release Allows technicians to disengage both column locks independently Heavy-Duty Arm Restraint System Oversize rugged steel gears, pins, and springs for trouble free operation. Double Telescoping Screw Pads/strong> Used with rubber pads offering 2.5” adjustment for complete vehicle coverage. *Standard Asymmetric (TLT240SC Only) Lift installed with columns facing each other. *Rotated Asymmetric (TLT240SC Only) Lift installed with columns offset - rotated.
