iDEAL IWA-60-2000T-K -3D IPRO IMAGE WHEEL ALIGNER SYSTEM

IWA-60-2000T-K Wheel Aligner by iDeal

Stay ahead of the electric vehicle curve with the iDEAL IWA-60-2000T-K Wheel Aligner, designed specifically for tackling the heavy components of EVs and hybrids. With a 2,500 lb capacity, this portable scissor lift can easily manage everything from battery packs to motors. Plus, its smooth hydraulic system ensures precise, safe control at every stage. Adjust tilt angles between +/- 4° to 8°, lock the platform at multiple heights, and enjoy hassle-free maneuvering with the insulated, sliding platforms and durable poly swivel casters.

Ready to revolutionize your workshop? This specialized lift, with its rugged powder-coated finish, keeps your shop primed for the future of EV maintenance. With three locking heights—49", 61", and 68"—and rapid lifting/lowering times, this scissor lift will streamline your workflow and keep you competitive in the growing EV market.

Wheel Aligner IWA-60-2000T-K Specifications:

• Lift Model: LT-EV2500AH-X
• Capacity: 2,500 lbs.
• Overall Length: 74.6"
• Overall Width: 35.4"
• Max EV Platform Height: 72.6"
• Min EV Platform Height: 35.4"
• Hand Bar Height: 39.2"
• EV Platform Size (L x W): 59" x 31.5"
• EV Platform Adj. Tilt Angle (+/-): 4° to 8°
• EV Platform Locking Heights: 49", 61", 68"
• Lifting / Lowering Rate: 72S / 33S
• Power Supply (Compressed Air): 90 - 125 PSI (6-9 Bar)
• Ship Weight: 978 lbs.

IWA-60-2000T-K Wheel Aligner Special Features:

• 2,500 lbs capacity for heavy-duty lifting.
• Innovative, high-quality portable scissor lift design for efficiency and durability.
• Safe and efficient method for installing or removing heavy EV or hybrid vehicle components, such as battery packs, motors, and powertrain assemblies.
• Full-operation air system hand controls for lifting, locking, and lowering.
• Compressed air/HP hydraulic operation (90 to 125 PSI) for reliable performance.
• Integrated air gauge with water separator for maintaining air system quality.
• Insulated, multi-directional sliding EV platform with six adjustable latch clamps for secure positioning.
• Heavy-duty jack screws for precise tilt and height adjustments.
• Double scissor heavy-duty design with a high-quality hydraulic cylinder.
• Integrated utility/tool tray and sub-platform storage area for convenience.
• Durable directional and locking 6" poly swivel casters for easy maneuverability.
• EV platform size: 59"L x 31.5"W.
• Three locking height positions for added safety.
• Maximum platform height: 72.6".
• Minimum platform height: 35.4".
• Overall size: 74.6"L x 35.4"W.
• Lift rise time: 72 seconds.
• Lowering time: 33 seconds.
• Includes four rubber pads (6.4"L x 4"W x 1.45"H) for added stability.
• Durable powder-coat finish for long-lasting protection.
• Ships from Montana and includes training.
• Buy as a Combo CK-FP14KA with CX-IWA-60-2000T-K and RAJ-7K-H
